Driven Face (Silver Fox (4 Stroke))
Change Assembly
| # | Product Name | Req'd | Price: | |
|---|---|---|---|---|
| 1 |
1 Drive Face Assembly (B)
22000-133-0A0
|
|||
| 2 |
1 Secondary Fix Slot Wheel
23200-133-0A0
|
|||
| 3 |
1 Face Ass'Y Driven
23210-133-0A0
|
|||
| 4 |
Radial Ball Bearing, 6901LU
96100-6901U
|
$15.82 | ||
| 5 |
Internal Cir Clip, IRTW-24
94512-240IR
|
$1.51 | ||
| 6 |
Needle Bearing, HKS-17*25*18
96200-172518
|
$18.45 | ||
| 7 |
1 Coller Spring
23238-133-0A0
|
|||
| 8 |
1 Compression Spring
23233-133-0A0
|
|||
| 9 |
1 Secondary Spring Seat
23237-133-0A0
|
|||
| 10 |
1 Oil Ring, 36*1.5
91336-133-0A0
|
|||
| 11 |
1 Oil Ring, 29.8*2.2
91339-133-0A0
|
|||
| 12 |
Oil Seal, 34*39*3
96500-34393
|
$4.76 | ||
| 13 |
1 Secondary Sliding Slot Wheel
23220-133-0A0
|
|||
| 14 |
3 Guide Pin
23225-133-0A0
|
|||
| 15 |
Plate Ass'Y Drive
22001-133-0A0
|
|||
| 16 |
Plate Comp Drive
22350-133-0A0
|
|||
| 17 |
Rubber Clutch Damper
22804-133-000
|
$11.86 | ||
| 18 |
Spring Clutch
22401-133-000
|
$2.01 | ||
| 19 |
Clutch Weight Set
22535-133-0A0
|
|||
| 20 |
Copper Plain Washer, 6.5*12*1
94101-0612010
|
$1.34 |
