Rear Wheel Ass'y (Dazon Raider 250 2005 and Older)
Change Assembly
| # | Product Name | Req'd | Price: | |
|---|---|---|---|---|
| 1 |
Swing Arm Comp., Bottom Rear
5212A-BDE0-0010
|
|||
| 2 |
Shock Absorber Assy., Rear
52400-BDE0-0000
|
$104.43 | ||
| 3 |
Axle Comp., Rear Wheel
41000-BDE0-0000
|
$219.40 | ||
| 4 |
Chain,Drive
40530-BDE0-0000
|
|||
| 6 |
Seal,Oil
91203-BDE0-0010
|
|||
| 8 |
Bearing
96100-60070-2RS
|
|||
| 9 |
Bolt, Flange M10*50
90140-10050-1B
|
$2.09 | ||
| 12 |
Seal, Oil
91204-BDE0-0010
|
$4.18 | ||
| 17-1 |
Battery
31500-BDB0-0000-M1
|
|||
| 17-2 |
Battery
31500-BDB0-0000-M2
|
|||
| 19 |
Damping Sleeve, Bottom Rear Swing Arm
52125-BDC0-0000
|
|||
| 20 |
Lock Nut,Flange
90210-08B01-2B
|
|||
| 22 |
Band, Battery
50329-BDE0-0000
|
$3.61 | ||
| 26 |
Bolt,Tire M10
44901-BCA0-0000-0C
|
|||
| 34 |
Wire Harness, Main
32400-BDE0-0000
|
|||
| 35 |
Wire Harness, Minor
32100-BDE0-0000
|
|||
| 41 |
250cc CDI Unit
30410-BDA0-0000
|
|||
| 42 |
Shroud, Brake Disc
45300-BDE0-0000
|
|||
| 44 |
Rectifier/Regulator Comp.
31600-BDA0-0000
|
$80.96 | ||
| 46 |
Rotor, Speed Sensor
37501-BDE0-E000
|
$69.23 |
