Bottom Rear Swing Arm (Dazon Raider 90 2005 and Older)
Change Assembly
| # | Product Name | Req'd | Price: | |
|---|---|---|---|---|
| 1 |
Swing Arm Assy.., Bottom Rear
5212A-BDD0-0010
|
|||
| 2 |
Bearing (with covers at two ends)
96100-62030-ZZ
|
$8.72 $6.54 | ||
| 3 |
Cover, Bearing Base
42702-BDD0-0010
|
$11.30 $8.47 | ||
| 4 |
Screw, Socket-head M8*30
90140-08030-1B
|
|||
| 5 |
Lock Nut,Flange
90210-08B01-1B
|
|||
| 6 |
Bolt, Flange M8*20
90140-08020-0B
|
$1.05 $0.79 | ||
| 7 |
Bearing (with covers at two ends)
96100-60050-ZZ
|
$10.98 $8.24 | ||
| 8 |
Bearing (with covers at two ends)
96100-60040-ZZ
|
$9.41 $7.06 | ||
| 9 |
Seat Ⅱ,Bearing
41204-BDD0-0000
|
$22.59 $16.95 | ||
| 10 |
Seat,Bearing
41203-BDD0-0000
|
|||
| 11 |
Rubber Collar, Rear Swing Arm
11102-BDD0-0000
|
|||
| 12 |
Shock Absorber ,Rear
53401-BDD0-0000
|
$55.23 $41.42 | ||
| 13 |
Bolt, Flange
90140-10040-1B
|
$2.09 $1.57 | ||
| 14 |
Lock Nut, Flange
90210-10B01-1B
|
|||
| 15 |
Bolt, Flange
90140-10055-1B
|
$1.81 $1.36 | ||
| 16 |
Battery
31500-TBA0-0000
|
$57.49 $43.12 | ||
| 17 |
Bolt, Flange
95710-06016-0C
|
$0.70 $0.52 | ||
| 18 |
Electric Box
50331-BDD0-0000
|
$24.14 $18.10 | ||
| 19 |
Band, Battery
50329-BCA0-0000
|
|||
| 20 |
Cover, Electric Box
50320-BDD0-0000
|
