Oil Pump (Adly ATV 90Z2 4T (Gear Drive))
Change Assembly
| # | Product Name | Req'd | Price: | |
|---|---|---|---|---|
| 1 |
Right Crankcase(Rev.1)
11101-152-000
|
$89.17 | ||
| 2 |
Crankcase Gasket
11191-152-000
|
$7.82 | ||
| 3 |
L. Crank Case Comp
11201-152-000
|
$145.74 | ||
| 4 |
Oil Pump Ass'Y
15100-152-000
|
$72.69 | ||
| 5 |
Oil Pump Gasket
15119-152-000
|
$1.09 | ||
| 6 |
Oil Pump Body
15111-152-000
|
|||
| 7 |
Oil Pump Pivot
15131-152-000
|
$5.18 | ||
| 8 |
Oil Filter Screen
15421-152-000
|
$8.22 | ||
| 9 |
Clamper,Carb Drain Tube
11351-152-000
|
$0.74 | ||
| 10 |
Stud Bolt, 6*202
91001-06202Z
|
$5.13 | ||
| 11 |
Stud Bolt, 6*195
91001-06195Z
|
$5.13 | ||
| 12 |
Plain Washer, 12*21.3*2
94104-1221320
|
$2.68 | ||
| 13 |
Dowel Pin, 8*10*14
94301-10140
|
$1.26 | ||
| 14 |
Hex Flange Bolt, 12*15
96000-12015-17C
|
$3.35 | ||
| 15 |
Pan Phillips Bolt, 6*16
93500-06016
|
$0.42 | ||
| 16 |
Pan Phillips Bolt, 6*22
93500-06022
|
$0.30 | ||
| 17 |
Hex Socket Bolt, 6*50
91000-06050C
|
$2.09 | ||
| 18 |
Hex Socket Bolt, 6*60
91000-06060C
|
$1.34 | ||
| 19 |
Hex Socket Bolt, 6*65
91000-06065C
|
|||
| 20 |
Radial Ball Bearing, 6203
96100-62030
|
$10.46 |
